Newly release products

Frequency (MHz)	H-Beam	Antenna Port Configuration	Model	Patterns	Bracket	Gain (dBi)	V-Beam °	L x W x D (inches)
3400-4200	OMNI									2		IX02OMI136-M4	Contact Customer Service	N/A	6.2	OMNI	8 x 2.75
617-3980	65°	2			IX02PNL165-65	Contact Customer Service	N/A	6.5 & 9.0 & 8.0	87.7 & 65.0 & 57.0	10.89 x 7.87 x 3.78

Frequency (MHz)

H-Beam

Antenna Port Configuration

Model

Patterns

Bracket

Gain (dBi)

V-Beam °

L x W x D (inches)

617-697

698-798

799-894

894-960

1695-2180

2180-2200

2200-2360

2360-2690

3400-3550

3550-3700

3700-3980

3980-4200

5150-5925

3400-4200

OMNI

IX02OMI136-M4

Contact Customer Service

N/A

6.2

OMNI

8 x 2.75

617-3980

65°

IX02PNL165-65

Contact Customer Service

N/A

6.5 & 9.0 & 8.0

87.7 & 65.0 & 57.0

10.89 x 7.87 x 3.78

Frequency (MHz)	H-Beam	Antenna Port Configuration													Model	Patterns	Gain (dBi)	V-Beam °	Diameter/ Height (inches)
Frequency (MHz)	H-Beam	617-697	698-798	799-894	894-960	1695-2180	2180-2200	2200-2360	2360-2690	3400-3550	3550-3700	3700-3980	3980-4200	5150-5925	Model	Patterns	Gain (dBi)	V-Beam °	Diameter/ Height (inches)
617-5925	OMNI	1													IV01OMI136-S4	Download	4.2 & 6.5 & 6.7 & 8.6	OMNI	8.0 x 2.75
617-5925	OMNI	1													IV01OMI136-T4	Contact Customer Service	N/A	3.0 & 4.3 & 4.0 & 4.6	OMNI
617-5925	OMNI	2													IV02OMI136-M4	Download	4.8 & 6.2 & 6.2 & 9.6	OMNI	8.0 x 2.75
617-5925	OMNI	1													IV01OMI136-U4	Contact Customer Service	4.1 & 4.0 & 4.7 & 5.4	OMNI	8.4 x 0.4
617-5925	OMNI	2													IV02OMI136-U4	Contact Customer Service	5.2 & 6.1 & 4.7 & 4.7	OMNI	10.5 x 0.4
3400-4200	OMNI									2					IX02OMI136-M4	Contact Customer Service	6.2	OMNI	8 x 2.75
617-3980	65°	2													IX02PNL165-65	Contact Customer Service	6.5 & 9.0 & 8.0	87.7 & 65.0 & 57.0	10.89 x 7.87 x 3.78

Frequency (MHz)	H-Beam	Antenna Port Configuration													Model	Patterns	Bracket	Gain (dBi)	V-Beam °	L x W x D (inches)
Frequency (MHz)	H-Beam	617-697	698-798	799-894	894-960	1695-2180	2180-2200	2200-2360	2360-2690	3400-3550	3550-3700	3700-3980	3980-4200	5150-5925	Model	Patterns	Bracket	Gain (dBi)	V-Beam °	L x W x D (inches)
617-894 & 1695-2690 & 3400-4200	28°	2													SX04FRO128-01	Contact Customer Service	91900324	10.7 & 11.6 & 13.9 & 13.1	60.9 & 50.2 & 45 & 48	14.6 x 24.25 x 7.9
617-894 & 1695-2690 & 3400-4200	28°									2					SX04FRO128-01	Contact Customer Service	91900324	10.7 & 11.6 & 13.9 & 13.1	60.9 & 50.2 & 45 & 48	14.6 x 24.25 x 7.9
617-894 & 1695-2690 & 3400-4200	65°	2													SX04FRO165-01	Contact Customer Service	91900324	7.3 & 12.6 & 14.5 & 11.3	79.3 & 24.2 & 16.3 & 49	15 x 14.6 x 6.4
617-894 & 1695-2690 & 3400-4200	65°									2					SX04FRO165-01	Contact Customer Service	91900324	7.3 & 12.6 & 14.5 & 11.3	79.3 & 24.2 & 16.3 & 49	15 x 14.6 x 6.4
1695-2690 & 3400-4200	20°					2				2					SX04FRO220-01	Contact Customer Service	91900324	18.2 & 19	22.2 & 20	15 x 25.3 x 3.75
617-894 & 1695-2690 & 3400-4200	30°	2													SX04FRO230-01	Contact Customer Service	91900324	13 & 14.6 & 14.6 & 13.8	35.4 & 27.5 & 37 & 40	24 x 24 x 8.5
617-894 & 1695-2690 & 3400-4200	30°									2					SX04FRO230-01	Contact Customer Service	91900324	13 & 14.6 & 14.6 & 13.8	35.4 & 27.5 & 37 & 40	24 x 24 x 8.5
617-2690 & 3400-4200 & 5150-5925	28°	2								4				2	SX08FRO128-01	Download	91900324	10.7 & 11.6 & 13.4 & 5.4	60.9 & 50.2 & 45 & 27.5	24.25 x 14.6 x 7.9
617-2690 & 3400-4200 & 5150-5925	30°	2								4				2	SX08FRO230-01	Download	91900324	13.0 & 14.6 & 14.1 & 5.5	35.4 & 27.5 & 37 & 33.5	24.0 x 24.0 x 8.5
617-960 & 1695-2690 & 3400-4200 & 5150-5925	65°	2								4				2	SX10FRO165-01	Download	91900324	7.3 & 12.6 & 11.6 & 5.5	79.3 & 24.2 & 45.7 & 31.0	15.0 x 14.6 x 6.4
617-960 & 1695-2690 & 3400-4200 & 5150-5925	65°					4									SX10FRO165-01	Download	91900324	7.3 & 12.6 & 11.6 & 5.5	79.3 & 24.2 & 45.7 & 31.0	15.0 x 14.6 x 6.4
3400-3700	65°									2					SX02FIT165-20	Contact Customer Service	919055	13.5	19.7	13.1 x 6.7 x 3.3
3400-3980	65°									2					SX02FIT165-4X	Contact Customer Service	N/A	13.3	21.2	9.0 x 3.0 x 2.17

Frequency (MHz)	H-Beam	Antenna Port Configuration													Model	Patterns	Bracket	Gain (dBi)	V-Beam °	L x W x D (inches)
Frequency (MHz)	H-Beam	617-697	698-798	799-894	894-960	1695-2180	2180-2200	2200-2360	2360-2690	3400-3550	3550-3700	3700-3980	3980-4200	5150-5925	Model	Patterns	Bracket	Gain (dBi)	V-Beam °	L x W x D (inches)
1695-2690 & 3550-3700 & 5150-5925	65°					4					4			2	DX10FRO260-00/06	Download	91900324	14.0 & 15.5 & 5.5	14 & 9 & 26	24.0 x 15.0 x 3.75
698-894 & 1695-2690 & 3550-3700 & 5150-5925	65°		2			4					4			2	DX12FRO260-20/26	Download	91900324	10.0 & 14.0 & 15.0 & 5.5	33 & 14 & 9 & 26	24.0 x 15.0 x 5.25
1695-2690 & 3400-3700 & 3700-4200	65°					8				4		8			DX20FRO265-01	Contact Customer Service	91900318	10.8 & 13.0 & 21.6	35 & 21 & 6.8	30.0 x 14.2 x 8.5
698-960 & 1695-2690 & 3400-4200	65°		4			8				8					DX20FRO265-04	Contact Customer Service	91900324	7.4 & 12.4 & 14.0	72 & 25 & 21.5	24.0 x 14.2 x 8.5
698-960 & 1695-2690 & 3400-4200	65°		4			12				8					DX24FRO265-04	Contact Customer Service	91900324	7.2 & 10.7 & 13.9	72 & 40 & 21.5	24.0 x 14.2 x 8.5
3550-3700	45°										4				MX04FIT345-01	Download	91900318	19.0	7.3	32.67 x 11.6 x 4.53
3550-3700	65°										4				MX04FIT365-01	Download	91900318	17.0	7.3	32.67 x 11.6 x 4.53
617-5925	360°	2													SV02UTS136-PT	Contact Customer Service		4.8 & 5.2 & 4.8 & 4.3	12.5 x 8.0 x 4.09

Antenna brackets and mounting hardware
91900324	BRACKET KIT, INSTALLATION, DX ANTENNA, STADIUM ANTENNA, ROTATIONAL
919055	BRACKET KIT, INSTALLATION, VENUE ANTENNA (INVERTED MOUNT)

Installation guide
81900511	Venue Bracket Antenna Installation Guide for 91900313, 91900324, 91900325, 91900340, and 919055 bracket kits
81900516	IV0XOMI136 Antenna Installation Guide for ceiling-mount antenna
81900518	SV02UTS136-PT Under-the-Seat Antenna Installation Guide
81900520	IV0XOMI136-T4 Antenna Installation Guide for ceiling-mount antenna
81900526-01	SX, DX, IX Venue Antenna Weep Hole Drill Guide
