| General | Specification | |||
|---|---|---|---|---|
| Cables supported | Andrew | FSJ1-50A | RFS | SCF14-50J |
| FSJ1RK-50B | SCF14-50JFN | |||
| PTS1-50-P | Eupen | EC1-50-HF | ||
| Hansen | RF5014S | Times | SPP-250-LLPL | |
| RF5014SZ | SPO-250 | |||
| HUBER+SUHNER | SUCOFEED 1/4 HFFR | |||
| SUCOFEED 1/4 HF | ||||
| Dimensions in. (mm) | 3.48 x 1.89 (88.3 x 48.0) | |||
| Weight | 0.08 lb | 36.3 g | |||
| Material | Silicone rubber | |||
| Lubricant | Dow Corning Molykote® III | |||
| Reusability | Unlimited | |||
| Environmental | Specification | Comment |
|---|---|---|
| Installation temperature | -40 °C to +65 °C (-40 °F to 149 °F) | |
| Operating temperature | -40 °C to +65 °C (-40 °F to 149 °F) | |
| Storage temperature | -55 °C to +85 °C (-67 °F to 185 °F) | |
| Moisture resistance | No leakage | ANSI/SCTE 60 2004, IP-67, IP-68 |
| Corrosion resistance | 1000 hours | ASTM B117 |
| U.V. resistance | Exposure to UV light for 1000 hours per ASTM G 53 using UVB-313 type lamps | |
| H.A.L.T. | 40 hours | |
| Fire rating | UL94 HB |
|
|
